Automatic Bar Feeder
Automatic Bar Feeder
- Highly cost-effective dual-purpose feeder.
- Capable of switching between dedicated mode and standard feeding mode.
- The material staging area length and capacity can be designed according to material length (up to 200 mm).
- Fast mode switching without modifying or removing the program.
- Feeding parameters can be adjusted according to customer requirements.
- Dedicated mode supports front or rear feeding.
- Servo-driven feeding provides high stability, low noise, and high efficiency.
- The loading and feeding mechanisms are stable with no waiting time, increasing processing efficiency.
SPECIFICATION
| Bar diameter | ⌀5mm~⌀65 mm |
| Maximum bar length | 200~1,500 mm |
| Magazine capacity | ⌀10 (61 pcs) |
| Power supply | 220V |
| Feed drive | AC servo motor |
| Controller & HMI interface | PLC control & Chinese HMI interface |
| Weight | 380 kg |
| Length | 2,300 mm |
| Height | 1,050~1,350 mm |
| Width | 1,090 mm |
| Center height | 900~1,200 mm |
